Code_Aster
®
Version
7.4
Titrate:
Procedure
PRE_GIBI
Date:
08/02/05
Author (S):
COURTEOUS Mr.
Key
:
U7.01.11-H
Page
:
1/4
Instruction manual
U7.0- booklet: Data exchanges
HT-66/05/004/A
Organization (S):
EDF-R & D/AMA
Instruction manual
U7.0- booklet: Data exchanges
Document: U7.01.11
Procedure
PRE_GIBI
1 Goal
To see a file of mesh to format GIBI then to write it with the format Aster.
The only levels of version of maillor GIBI (maillor of CASTEM 2000) treated are levels 3,
4, 5, 6, 8, 9, 10, 11 and 13. In CASTEM 2000, the file of mesh to format GIBI is produced by
directive TO SAVE FORMAT.
For the rules of transcription of a file of mesh of GIBI in Aster to refer to the booklet
[U3.04.01].
One does not read again any more the files results of maillor GIBI produced by the directive
LEAVES
, one does not read again not
more the files result of maillor GIBI created by the directive
TO SAVE
who produces files result
of binary type (to use well
TO SAVE
FORMAT
).
Code_Aster
®
Version
7.4
Titrate:
Procedure
PRE_GIBI
Date:
08/02/05
Author (S):
COURTEOUS Mr.
Key
:
U7.01.11-H
Page
:
3/4
Instruction manual
U7.0- booklet: Data exchanges
HT-66/05/004/A
3 Operands
3.1 Operand
UNITE_GIBI
UNITE_GIBI = unilec
Logical number of the file of result of GIBI (reading), is worth 20 per defect what corresponds to
mgib type in the interface astk.
3.2 Operand
UNITE_MAILLAGE
UNITE_MAILLAGE = uniecr
Logical number of the file mesh Aster (writing), is worth 19 by defect which is also the defect
LIRE_MAILLAGE and corresponds to the mall type of astk.
